額定載荷 Rated capacities(Emax) |
0.5、1、2、3、5、10、20T |
|
輸出靈敏度 Rated output |
2.0(3.0)±10%mV/V |
|
綜合誤差 Total error |
0.05~0.1%F.S |
|
非線性 Non-linearity |
0.05%F.S |
|
滯后 Hysteresis |
0.05%F.S |
|
重復(fù)性 Repeatability |
0.05%F.S |
|
蠕變(30分鐘)Creep(30min) |
0.05%F.S |
|
零點輸出Zero balance |
±2%F.S |
|
零點溫度漂移 Temperature effect on zero |
±0.05%F.S/10℃ |
|
溫度靈敏度漂移 Temperature effect on out |
±0.05%F.S/10℃ |
|
輸入阻抗 Input resistance |
385±10Ω |
|
輸出阻抗 Output resistance |
350±5Ω |
|
絕緣電阻 Insulation resistance |
≥5000MΩ/100DC |
|
度補償范圍 Compensated Temperature range |
-10～+50℃ |
|
工作溫度范圍 Operation Temperature range, |
-35~+65 ℃ |
|
安全過載 Maximum safe overload |
120 %F.S |
|
極限過載 Ultimate overload |
200 %F.S |
|
推薦激勵電壓 Excitation,recommend |
5-10V DC |
|
最大激勵電壓 Excitation,maximum |
15V DC |
|
防封等級 Protection Class |
IP66 |
|
電纜尺寸 Cable size |
Φ2.5×3000mm |
