簡單描述
CPCI接口的CAN通訊卡,含1至4個CAN口,支持CANopen和DEVICENET協議,智能卡和非智能卡,提供豐富的函數庫和軟件
詳細介紹
*interface from CompactPCI to one or two independent CAN nets
*3 HE board with microcontroller 68331 on board
*extended temperature option
*CAN controller SJA1000, CAN 2.0A/B
*CAN interfaces electrically isolated and designed acc. to ISO 11898
*bit rate up to 1 Mbit/s
*software examples for DOS and Windows 3.11 in source code
*software drivers available for many operating systems
*CANopen master-slave object licence available
*also available for DeviceNet
